It is widely recognized that process
variation is emerging as a fundamental challenge to IC design in scaled
CMOS technology; and it will have profound impact on nearly all aspects of
circuit performance. While some of the negative effects of variability can
be handled with improvements in the manufacturing process, the industry is
starting to accept the fact that some of the effects are better mitigated
during the design process. Handling variability in the design process will
require accurate and appropriate models of variability and its dependence
on designable parameters (i.e. layout), and its spatial and temporal
distributions. It also requires carefully designed test structures and
proper statistical data analysis methods to extract meaningful models from
large volumes of silicon measurements. The resulting compact modeling of
systematic, random, spatial, and temporal variations is essential to
abstract the physical level variations into a format the designers (and
more importantly, the tools they use) can utilize. This workshop provides a
forum to discuss current practice as well as near future research needs in
test structure design, variability characterization, compact variability
modeling, and statistical simulation.
Key Topics
Physics mechanisms and technology trends of device-level variations
First-principles simulation methods for predicting variability
Time-dependent variation and their interaction with other variation sources
Compact modeling of variations in devices and interconnect
Device and circuit level modeling techniques
Test structure design for variability
Variability characterization, bounding and extraction
Statistical data analysis and model extraction methods
Novel implementation and simulation techniques for dealing with variability
Tentative Agenda
9:00 – 9:10am Opening Remarks
9:10 – 9:50am Keynote:
Rob Aitken (ARM): Knowns and Unknowns in Variability Modeling
9:50 – 10:30am
Takayasu Sakurai (Univ. of Tokyo): Deep-volt Design under Variability
10:30 – 11:00am
Morning Break/Discussion
11:00 – 11:40am
Vijay Reddy (TI): An Overview
of Circuit Aging in SOCs
11:40 – 12:20pm
Gilson Wirth (UFRGS): Charge
Trapping Phenomena in MOSFETs: From Noise to Bias Temperature Instability
12:20 – 1:30pm
Lunch
1:30 – 2:10pm Keynote:
Luigi Capodieci (GF): DFM Methodologies for Effective Variability Management in Physical
Design at 20nm and Beyond
2:10 – 2:50pm Kiyoshi Takeuchi (Renesas): Impact
of Random Telegraph Noise on Circuit Reliability
2:50 – 3:30pm Poster Presentation
3:30 – 4:00pm Afternoon Break/Discussion
4:00 – 5:00pm Poster Session
|
