It is widely recognized that
process variation is emerging as a fundamental challenge to IC design in scaled
CMOS technology; and it will have profound impact on nearly all aspects of
circuit performance. While some of the negative effects of variability can
be handled with improvements in the manufacturing process, the industry is
starting to accept the fact that some of the effects are better mitigated
during the design process. Handling variability in the design process will
require accurate and appropriate models of variability and its dependence
on designable parameters (i.e. layout), and its spatial and temporal
distributions. It also requires carefully designed test structures and
proper statistical data analysis methods to extract meaningful models from
large volumes of silicon measurements. The resulting compact modeling of
systematic, random, spatial, and temporal variations is essential to
abstract the physical level variations into a format the designers (and
more importantly, the tools they use) can utilize. This workshop provides a
forum to discuss current practice as well as near future research needs in
test structure design, variability characterization, compact variability
modeling, and statistical simulation.
Report from VMC
2009: PDF
Key
Topics
 Physics mechanisms and
technology trends of device-level variations
First-principles
simulation methods for predicting variability
Time-dependent variation and their interaction with other
variation sources
Compact modeling of
variations in devices and interconnect
Device and circuit level
modeling techniques
Test structure design for
variability
Variability
characterization, bounding and extraction
Statistical data analysis and model extraction methods
Novel implementation and
simulation techniques for dealing with variability
Tentative Agenda (talk
abstract in PDF)
8:20 –
8:30am Opening Remarks
8:30 –
10:00am Session I: Atomistic-Level Variations
Scott Roy
(Univ. of Glasgow): Atomistic Simulation of Variability
Tsu-Jae King
Liu (UC Berkeley): Nanoscale Transistor Design Optimization in
Consideration of Atomistic Effects
Naoki Tega
(Hitachi America): Study on
Variability in Transistor Characteristics due to Random
Telegraph Noise
10:00 –
10:30am Morning Break/Discussion
10:30 –
12:00pm Session II: Process Induced Variations
Paul Newman
(Intel): Topology
Matters: When a Sensitive Circuit Meets Transistor Variation
Puneet Gupta
(UCLA): Revisiting
Variation Models and Their Reliability
Victor Moroz
(Synopsys): Modeling Layout-Induced Proximity Effects
12:00 –
1:30pm Lunch
1:30 –
3:00pm Session III: Emerging Parametric
Variations and Extraction
Tanya Nigam
(Global Foundries): Challenges of Predicting Product Level Degradation
from Simple Device Level Models
Abe Elfadel
(IBM): Efficient Techniques for Variation-Aware
Electrical Modeling adn Verficication of VLSI Interconnect
Xin Li
(CMU): Virtual Probe: Minimum-Cost Silicon Characterization of Nanoscale
Integrated Circuits
3:00 –
3:30pm Afternoon Break/Discussion
3:30 –
5:00pm Session IV: Characterization of Device
and Circuit Variability
Vikas
Chandra (ARM): Challenges of Designing Robust Physical IP in Nanoscale
CMOS Technologies
Lawrence
Clark (ASU): In-Situ Characterization of SRAM Variability
Chris Kim
(Univ. of Minnesota): On-Chip Reliability Monitors: Circuit Ideas,
Measurements and Limitations
5:00 –
5:10pm Closing Remarks
|
